Hydraulic Power Pack KPS37
Product Detail
Technical specification of KPS37
|
Model |
KPS37 |
|
Working medium |
32# or 46# anti-wear hydraulic oil |
|
Fuel tank volume |
470 L |
|
Max. flow rate |
240 L/min |
|
Max. operating pressure |
315 bar |
|
Motor power |
37 KW |
|
Motor frequency |
50 Hz |
|
Motor voltage |
380 V |
|
Motor working speed |
1460 rpm |
|
Working weight (full tank) |
1450 kg |
|
Wireless control distance |
200 m |
Matches between pump station and hydraulic pile breaker:
|
Pump station model |
Round pile breaker model |
Square pile breaker model |
|
KPS37 |
KP380A |
KP500S |
Installation steps of hydraulic pile breaker and the pump station:
1. Put the pump station and pile breaker hang to the designated spot.
2. Use cable to put the external power connected with the pump station, make sure the indicator light without error.
3. Use hose to put the pile breaker connected with the pump station and install securely.
4. Through the observation mouth to check whether there is enough hydraulic oil in the fuel tank of the pump station.
5. Opening motor and operating the cylinder telescopic movements, making the hose and fuel tank full with oil.
6. Craning the pile breaker to cut piles.
Performance
1. Technical improvement with variable adjustment of power output, high efficiency and environment protection;
2. International first-class air cooling makes motivation for a long time;
3. Using high quality parts can be trustworthy.
Product Show
Package
